| Printing method: | Direct Thermal/Term Transfer |
| Resolution: | 203 dpi (12 dots/mm) |
| Print speed: | 5IPS (127 mm/s) |
| Print width: | 4.09" (104mm) |
| Print length: | Min. 0.16 (4mm); Max 45 (1143mm) |
| Processor | 32 Bit RISC CPU |
| Memory | 8MB Flash (4MB for user storage) / 16MB SDRAM |
| Media | Width: 1 (25.4 mm) Min. - 4.64 (118 mm) Max. Thickness: 0.003 (0.06 mm) Min. - 0.01 (0.25 mm) Max. Sticker Roll Diameter: Max. 8 (203.2 mm) , Max. 6 (152.4 mm) Core Diameter: 3, 1.5 (76.2 mm, 38.1 mm) |
| Carbon tape: | Type: Wax, wax/resin, resin Length: 1471' (450 m) Width: 1.18 Min - 4.33 (30 mm - 110 mm) Max Roll Diameter: 2.99 (76 mm) Core Diameter: 1 (25.4 mm) |
| Printer supported languages | EZPL, GEPL, GZPL auto switch |
| Software: | GoLabel (EZPL only) Driver and DLL: Windows 2000, XP, Vista, 7,8, Windows Server 2003 & 2008 |
| Existing fonts: | Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable Bitmap fonts 8 times expandable in horizontal and vertical directions Scalable fonts 90°, 180°, 270° rotatable |
| Downloadable fonts: | Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions Scalable fonts 90°, 180°, 270° rotatable |
| Barcodes: | 1-D Bar codes: Code 39, Code 93, Code 128 (subset A, B, C), UCC/EAN-128 K-Mart, UCC/EAN-128, UPC A/E (add on 2 & 5), I 2 of 5, I 2 of 5 with Shipping Bearer Bars, EAN 8/13 (add on 2 & 5), Codabar, Post NET, EAN 128, DUN 14, HIBC, MSI (1 Mod 10), Random Weight, Telepen, FIM, China Postal Code, RPS 128 and GS1 DataBar 2-D Bar codes: PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code, Aztec code |
| Encoding: | CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737 WINDOWS 1250, 1251, 1252, 1253, 1254, 1255,1257 Unicode (UTF8, UTF16) |
| Graphics: | Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software |
| Interfaces: | Serial port: RS-232 (DB-9) USB 2.0 Ethernet 10/100 Mbps USB Host |
| Control Panel: | Color TFT LCD with navigation button Power on/off button Calibration button |
| Power supply: | Auto Switching 100-240VAC, 50-60Hz |
| Environment: | 41°F to 104°F (5°C to 40°C) Storage temperature: -4°F to 122°F (-20°C to 50°C) |
| Humidity: | Operating: 30-85%, non-condensing. Storage: 10-90%, non-condensing. |
| Certified: | CE(EMC), FCC Class A, CB, cUL, CCC |
| Dimensions: | Length: 20.15 (512 mm) Height: 20.15 (512 mm) Width: 10.78 (274 mm) |
| Weight: | 33 lbs (15Kg), without accessories |
| Available modifications: | Sticker cutter Sticker cutter+Internal sticker wrapper External sticker roll holder 10 (250 mm) External sticker wrapper External sticker wrapper Parallel port adapter module (Centronic female 36-pin) Applicator interfaces (1 input, 3 outputs, power supply 500mA @ 5V, for project base) |
